Original price was: $3,950.00.$3,650.00Current price is: $3,650.00.
Battery Capacity:
Lithium Iron Phosphate (LiFePO4)
Configuration: 16S1P
Capacity: 102AH / 51.2V
Energy: 5222Wh (5.2 kWh electricity)
Inverter Parameters:
Model: 5KW 48V (SKU AEV)
Rated Output Power: 5KVA / 5KW
Output Voltage Waveform: Pure sine wave
Output Voltage Regulation: 230VAC ±5%
Output Frequency: 60Hz or 50Hz
Public Facility Charging Mode:
Charging Current (UPS) @ Standard Input Voltage: 60A
Floating Charging Voltage: 54VDC
Solar Charging Mode:
Power Range: < 5.5KW
PV Charging Current: 80A
Efficiency: Maximum 98%
PV Array MPPT Voltage Range: 120–450VDC
Physical Specifications:
Dimensions: 385 x 535 x 335 mm
Material: Sheet metal
Color: White and Black (customizable colors available)
Product Weight: Approx. 60 kg
Packaging Size: 660 x 500 x 600 mm
Battery Capacity:
Lithium Iron Phosphate (LiFePO4)
Configuration: 16S1P
Capacity: 102AH / 51.2V
Energy: 5222Wh (5.2 kWh electricity)
Inverter Parameters:
Model: 5KW 48V (SKU AEV)
Rated Output Power: 5KVA / 5KW
Output Voltage Waveform: Pure sine wave
Output Voltage Regulation: 230VAC ±5%
Output Frequency: 60Hz or 50Hz
Public Facility Charging Mode:
Charging Current (UPS) @ Standard Input Voltage: 60A
Floating Charging Voltage: 54VDC
Solar Charging Mode:
Power Range: < 5.5KW
PV Charging Current: 80A
Efficiency: Maximum 98%
PV Array MPPT Voltage Range: 120–450VDC
Physical Specifications:
Dimensions: 385 x 535 x 335 mm
Material: Sheet metal
Color: White and Black (customizable colors available)
Product Weight: Approx. 60 kg
Packaging Size: 660 x 500 x 600 mm
